Brembo: Official Partner

GT-1T-.9016A (GT Systems)

Product Details

Images are for representational purposes only. Actual product may vary.

TY3

  • Red
    1T3.9016A2
  • Black
    1T3.9016A1
  • Yellow
    1T3.9016A5
  • White
    1T3.9016A6
  • Fluorescent Yellow
    1T3.9016A7
Product Overview
Product Description:

(F) 6-Piston Cast Monobloc Calipers | 380x34mm (15'') 2-Piece Discs | Complete Axle Set | Pre-Assembled | All Necessary Hardware Included

Front or Rear System Shown:
Front
Intended Use:
StreetTrackRace
System Dynamics:
Notes:
This system does not include brake lines, the OEM brake lines are retained. | The disc bells in this system are finished in natural hard anodize, exhibiting a greyish color, different from the black used on most GT systems. | Heavy-duty disc with smaller airgap
Caliper
Caliper Body:
Cast Monobloc Radial Mount
Caliper Piston Configuration:
6-Piston
Caliper Piston Design And Insert Type:
Inner Pressure Seal / OEM Approved Dust Boot
Disc
Disc Type:
TY3
Disc Material/Finish:
Advanced High Carbon Alloy / Corrosion Resistant Plating
Disc Diameter:
380mm
Disc Width (Measurement):
34mm
Disc Air Gap (Measurement):
17mm
Disc Annulus (Measurement):
65mm
Disc Construction:
2-Piece Disc Assembly
Disc Vane Design (Measurement):
Vented Curved 72 Vane
Disc To Hat Mounting System:
Floating D-Bobbin with Anti Rattle Spring
Included Hardware
Mounting Hardware:
Brembo Engineered CNC Billet Caliper Adapters - All Necessary Hardware Included For Ease of Installation
$5,095.00 USD
